heat pipe series

SK serials is heat pipes solar collector ,It is a absorb sun energy device in split pressure system. Very suitable for hot water heating, pool heating, space heating or even air conditioning.It have more efficiency than normal solar heater.

Solar collector manifold
Outer Body-high grade Aluminium /304 L stainless steel:
 - Rust Proof
 -Offers better Heat Retention
 -UV Resistant and durable

High grade Copper pipe In the manifold :
-High grade pure copper pipe .(1 mm thickness)
 -Automatic Plasma-TIG welding for flawless and corrosion resistant joints
 -Specially treated for enhanced protection in bad water areas

Maximum Hot zone:Hot zone - tank volume above the tube insertion point C 87%
Delivers 7% more hot water than other evacuated tube solar water heaters.
Evacuated tube collector
- Evacuated tube C optimised length:1800 mm long evacuated tube for high energy absorption.
- Higher efficiency as per international standards.
- AL-CU-SS on the surface of the tube. Increase more efficiency.

Heat pipe
-pure copper heat pipe ,1mm thickness
- heat transfer capacity of >120Watts.
-Special anti-freeze liquide inside,Still working in -30 degree.

Sun-Max reflector
-V-shaped reflectors for superior absorption.
 -Full length reflector fins C no gaps - for Max reflection.
 -Special grade material for reflectivity of upto 90% - optimum reflection back to the tubes.

Advantage of SNUG SOLAR
CharacteristicsSNUG SolarOthersSNUG    advantage
Outer BodySpecial grade    Aluminium or 304LSS304/FRP/ALNon    corrosive, durable and dent proof
Inner copper    pipePure    copper,1mm thicknessNormal    copper less than 1mmMore    efficiency,Durable and corrosion resistant
Pressure    bear2.5Mpa1.2 MpaMore    pressure more security
Container    weldingWelded by advanced    Automatic Plasma-TIG welding machinesManual    welding machinesUniform    welding, strong and corrosion resistant joint
ReflectorUnique    V-shaped SUN-MAX reflectorFlat    aluminum or SS reflectorSuperior    absorption ability
Reflectivity85%Not    avaliableOptimum    reflection
Glass tubeSS-Al-CU    Three coatingSS-AL two    coatingHigh    absorption efficiency
Heat pipepure    copper heat pipe ,1mm thickness ,anti-freeze system0.6mm    thickness, Stop working below-10 degreeWorking in    -30degree
Electrical    back up99.9% pure    copper tubularNot    specifiedLong life    and high efficiency
Guarantee7 years3 yearDependable
Model
Product ModelTubesCapacityAbsorbingWeightLWH(mm)20FT/40FT/40HQ
SK-1800/58-1212120L0.9240160010101430112 / 224 / 272
SK-1800/58-1515150L1.155016001350143093 / 186 / 226
SK-1800/58-1818180L1.376016001590143078 / 156 / 190
SK-1800/58-2020200L1.526616001750143071 / 142 / 173
SK-1800/58-2424240L1.838516002070143061 / 123 / 150
SK-1800/58-3030300L2.2910216002550143050 / 100 / 121
